TMV 2405S
Manufacturer:
TRACO Power
Mfr.Part #:
TMV 2405S
Datasheet:
Description:
DC to DC Converters SIP-7 Module, 4 Leads Through Hole Nominal Input Voltage:24 V Min Input Voltage:21.6 V Max Input Voltage:26.4 V 71 %
| Parameter | Value |
|---|---|
| Length | 19.5 mm |
| Width | 6.1 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 4 |
| Height | 10.2 mm |
| Packaging | Tube |
| Depth | 6.1 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Weight | 2.1 g |
| Min Input Voltage | 21.6 V |
| Output Current | 200 mA |
| Output Voltage | 5 V |
| Max Input Voltage | 26.4 V |
| Number of Outputs | 1 |
| Isolation Voltage | 3 kV |
| Output Power | 1 W |
| Efficiency | 71 % |
| Nominal Input Voltage | 24 V |
| Isolation | Isolated |
| Output Current-Channel 1 | 200 mA |
| Output Voltage-Channel 1 | 5 V |
Stock: 1449
Distributors
pcbx
pcbxUnit Price$4.06776
Ext.Price$4.06776
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $4.06776 | $4.06776 |
| 10 | $3.89848 | $38.98480 |
| 25 | $3.82294 | $95.57350 |
| 50 | $3.74887 | $187.44350 |
| 100 | $3.69244 | $369.24400 |
| 300 | $3.62295 | $1086.88500 |
| 500 | $3.55480 | $1777.40000 |
